Effisus Ecork Facade

Airtightness and water vapour management integrated system for facades with cork insulation

Effisus Ecork Facade system is the integrated system that brings together, in a single system, the benefits of the sealing and water vapor management system  for facades –  Effisus Ecofacade Envelope – and the 100% sustainable solution – Effisus Ecork.

Eliminates the possibility of condensation and conditions associated with moisture, maximizing energy efficiency and acoustics.

The Effisus Ecork system for facades is highly differentiated in terms of sustainability, not only because of the incorporation of Effisus Ecork cork, but also because of the protection that gives the building and the atmospheric elements, promoting indoor air quality and health of users.

Why should you choose Effisus Ecork Facade System?

Efficiency

  • Complete and integrated system
  • “Cutting Edge technology”
  • Excellent thermal and acoustic insulation properties
  • Waterproofing solutions with inteligent facade water vapor management
  • Unique thermal delay properties
  • Technical support from design to construction
  • Certified contractors
  • Superior resistance to wind action
  • Excellent puncture and tear resistance
  • Excellent resistance to UV’s and high temperature ranges
  • Excellent chemical compatibility and resistance to microbiological attack

Sustainability

  • The most sustainable solution on the market
  • Elevated longevity
  • Promotes indoor air quality  and users’ health
  • 100% natural and recyclable insulation
  • High product life-expectancy
  • Reduced maintenence needs
  • “Energy Star certification”
  • Without plasticizers
  • Without chlorides, halogens or other harmful chemicals to the environment
  • Low energy consumption in the production, installation and use
  • Optional gasket system with no need of adhesives
  • Reduced wastes through solution customization

Effisus Ecork Facade – Airtightness and water vapour management integrated system for facades with cork insulation

amorim

The best solutions are a result of the best partnerships.

The Effisus Ecork system results from a long-term industrial partnership with the world’s largest producer of cork, Corticeira Amorim.

The cork choice

Cork is a 100% natural and ecological product, endowed with a constitutional inviolability, with guaranteed efficiency. Among the natural substances is one that has greater insulating power. By choosing to use cork inyour project, you will be contributing to the protection of the environment, while enjoying all the advantages offered by the technical and acoustic characteristics of the material.

Ecofacade Envelope

Effisus Ecofacade Envelope – Ventilated Facades

System Components

  • Effisus Ecofacade/Effisus Ecofacade Inside Membranes – Waterproofing membranes resistant to UV’s and ozone with an expected durability of 50 years. With an elongation of up to 300%, it maintains its elasticity between -40ºC and +140ºC, absorbing the movements of thermal or structural origin of the building. Suitable for sealing connections between different facade elements.
  • Effisus Ecofacade SA-Edge Membrane – Waterproofing membrane with one or more embedded self-adhesive bands for application without the need for additional adhesives.
  • Effisus Ecofacade P-Fix  Membrane – Waterproofing membrane with  a quick-connection profile for fastening to the frame or facade without the need for additional accessories.
  • Effisus Ecork Insulation -Cork insulation, developed and produced according to the specific Effisus Ecoroof system characteristics and requirements. 100% natural and recyclable with excellent properties of thermal and acoustic insulation. Excellent resistance to compression and optimal behavior in the absorption of vibrations. Its unique thermal delay properties give the building an exceptional protection against temperature variations.
  • Effisus Breather+ Membranes    Impermeable and breathable membrane, with 3 layers. With high puncture resistance and superior resistance to wind passage. Ensures the tightness of the facade, allowing the aeration of thermal insulation.
  • Effisus Vap Membranes – Vapor barrier with superior aging resistance features, especially designed to ensure air tightness.
