Effisus TiteJoint3
Sealing High-Movement Metal Roof Joints
Effisus TiteJoint3 is a customizable solution for sealing demanding metal roofing joints, especially slip lap connections subject to frequent movement. It ensures long-lasting weatherproofing, with high resistance to UV exposure and extreme temperatures, combining a robust EPDM membrane, a high-performance double-sided tape, and a durable perimeter sealant with strong UV resistance.
Slip lap joint
Metal roofing systems has multiple transitions between panels. Slip lap joints, commonly used where significant movement is expected, present a particularly demanding challenge for effective weatherproofing. Effisus TiteJoint3 is a customizable solution tailored to project requirements, delivering a long-lasting weatherproofing seal capable of accommodating continuous joint movement caused by thermal expansion and contraction. It offers reliable performance under UV exposure and across extreme temperature ranges. This application-specific composite solution combines a highly robust EPDM membrane, a double-sided sealing tape with immediate tack, and a durable perimeter sealant with strong UV resistance.
| Essential characteristics | Method | Result |
|---|---|---|
| Thickness | EN 1848-2 | 1,30 mm (-5% / +10%) |
| Length | EN 1848-2 | ≥ 20 (lm) |
| Width | EN 1848-2 | 100–1300 mm ± 0.2% |
| Density | EN 1849-2 | 1.575 kg/m² |
| Watertightness | EN 1928 A | W1 (pass) |
| Airtightness | EN 12114 | ≤ 0.1 m³/(m²·h) (50 Pa) |
| Water vapour permeability (µ) | EN 1931 | 60.000 ± 18.000 |
| Tensile strength | EN 12311-2 B | ≥ 8.5 N/mm² |
| Tensile elongation | EN 12311-2 B | ≥ 350% |
| Resistance to nail tearing | EN 12310-1 | ≥ 110 N |
| Reaction to fire | EN 13501-1 | Class E |
| Resistance to artificial ageing | EN 1296 EN 1931 |
In accordance |
